Factory stock high stability vacuum pump oil does not contain hydrogen
Product introduction：
JVF vacuum pump oil is a linear perfluoropolyether polymer based on carbon, fluorine and oxygen. These three elements play an important role in this product as high-performance vacuum pump oil in vacuum pump. The thermal stability of JVF is different from that of the traditional vacuum pump because it contains hydrogen
CF3-[(O-CF-CF2)m-(O-CF2)n]O-CF3
| CF3
Product features：
*Low saturated vapor pressure * Good chemical inertness
*Excellent thermal stability * Good lubrication performance
*No flash point or ignition point * Safe and non-toxic
* Good solvent resistance * Low surface tension
*Excellent dielectric properties *Excellent radiation stability * No pollution to the environment
*Excellent compatibility with metals, plastics and elastomers
| Steam pressure | @ 25℃（torr） | 7×10-7 | 1×10-7 | 2×10-6 | 5×10-8 | ||
| @ 100℃（torr） | 3×10-7 | 2×10-4 | 2×10-4 | 5×10-8 | |||
| Heat of evaporation 200℃（ cal/g ） | 11 | 8 | 8 | 7 | 7 | 5 | |
| Proportion（ASTM D891）20℃（g/cm³） | 1.88 | 1.89 | 1.89 | 1.91 | 1.91 | 1.92 | |
| Surface tension（dyne/cm） | 21 | 22 | 22 | 22 | 24 | 24 | |
| Evaporation loss 22hrs | @ 120℃（% by wt） | 3 | 2 | 1 | 0.5 | ||
| @ 149℃ | 10 | 5 | 3 | 1 | |||
| Ultimate total pressure（torr） | 1.7×10-3 | 1.4×10-3 | 2.4×10-3 | 1.2×10-3 | |||
| Oil consumption rate（cm³/hr） | 0.4 | 0.6 | 0.5 | 0.7 | |||
